Dynamic Air Systems for Commercial HVAC Filtration

In independent lab testing, ECOairflow's Electronic Polarization Technology captured 74.73% of PM0.1 ultra-fine particles — 50% more effective than HEPA's 49.19% under the same controlled conditions. Unlike HEPA, ECOairflow filters maintain extremely low pressure drops, significantly reducing fan energy costs in commercial air handlers.

Yes. The M-Series 2" Hybrid EAC is ASHRAE 170 compliant. MERV 14A is approved for emergency rooms, invasive procedure rooms, and treatment areas; MERV 16A is approved for operating rooms and high-acuity procedural spaces. The system also complies with CSA Z317.2 for Canadian healthcare facilities.

An independent 12-week hospital study documented a 54% reduction in total fan power consumption compared to a traditional ASHRAE 170-compliant MERV 8 pre-filter plus MERV 14 bag filter train, using identical air handlers. Pressure drop ranges from 0.13–0.37 in.w.c. versus 0.6–1.2 in.w.g. for conventional hospital filter configurations.

Yes. ECOairflow commercial filters are eligible for LEED EQ credits supporting indoor air quality and ventilation efficiency. They also comply with the WELL Building Standard, International Living Future Institute (ILFI), National Green Building Standard (NGBS), and Passivehaus standards, and support ASHRAE 62.1 (2022) IAQ Procedure compliance through filtration over dilution.

Yes. The Dynamo 2" Model 2300 is compatible with existing 2" aluminum frames and can replace legacy commercial electronic air cleaner systems from brands such as Honeywell, AprilAire, and Lennox using the Cabinet Conversion Kit for adapter installation. The M-Series pad can also be swapped into existing Model 2300 frames to upgrade to hospital-grade ASHRAE 170 compliance.

ECOairflow provides a 5-year limited warranty on all components for the Model 2300 and M-Series commercial products from the date of manufacture. USA-based toll-free technical support is available at 1-877-347-3569 (8am–6pm ET). Submittal documentation, ASHRAE compliance docs, and LEED credit documentation are available on request for specifying engineers.
